TWINFIX GLAZING SYSTEMS

Roof Glazing Bar Systems for use with Glazing Polycarbonate

Plastics have large coefficients of thermal expansion. As they are also good heat insulators, they will become warmer than the surrounding air in direct sunlight. To avoid inducing stress and eventual failure, glazing panels must remain free to move relative to the roof structure, with these temperature changes. Twinfix glazing bar and panel systems are specifically designed to solve this problem and offer elegant solutions to three different applications. One installing structured polycarbonate roof glazing two replacing Georgian wired glass roof lights three security over glazing using solid polycarbonate.

Applications: These include commercial and industrial roof lights, school walkways and covers, hospital corridors, station canopies, supermarket entrances, conservatories and lean-to extensions. Twinfix offer a complete range of profile systems, either to utilise existing rafters, as replacements to glass glazing systems, or as structural glazing bars. Capable of accepting material from 4mm to 25mm thickness.

261 Rafter Gasket System

For use with Multi-wall Polycarbonate Sheet in Pitched Roofglazing Applications



226/7 Aluminium Glazing Bar System

For use with Multi-wall Polycarbonate Sheet in Pitched Roofglazing Applications

280 Aluminium Structural Glazing Bar System

For use with Multi-wall Polycarbonate Sheet in Pitched Roofglazing Applications





For Full details and prices on the " TWINFIX " range of fixings please contact us to discuss your  requirements.



CLADDING MATERIALS

Matt Foam PVC Sheet White & Colours

Suitable for most types of cladding, shops, butchers, clean areas, abattoirs, sealing porous and dusty areas, fascia panels. Full range of PVC profiles, rivets etc. for fastening the sheets

PVC foam sheet is produced in much the same way as most extruded sheet, passing through rollers to control thickness and surface finish. The fine cell structure and a smooth surface finish make it an ideal material for screenprinting, vinyl application, POS, advertising and sign applications. It is tough high impact resistance and low density 0.7 which makes it light and easy to machine. Can be used outdoors but precautions must be taken to allow for adequate expansion therefore, it is recommended to hang the sign.

Foamalite

Foamalux

Forex

Palight

The above brands are available in White: thickness from 1 to 6, 8 & 10mm.

Colours Available: Black, Light Grey, Dark Grey, Light Yellow, Golden Yellow, Red, Light Green, Dark Green, Light Blue, Dark Blue, Beige: in 3 & 5mm only

2440 x 1220

3050 x 1220

3050 x 1560

3050 x 2050

The above sheet sizes are available in White on most brands

Colours are only available in 2440 x 1220 at present

Gloss Foam PVC Sheet White & Colours

Generally as above but with hard acrylic coating on one face to give added resistance.

Foamalite Gloss

Foamalux Ultra

Forex Top

Palight 2001

The above brands are available in White: thickness in 3, 5 & 10mm.

Colours Available: Black, Grey, Yellow, Red, Green, Blue, in 3 & 5mm only

2440 x 1220



3050 x 1220



The above sheet sizes are available in White on most brands

Colours are only available in 2440 x 1220 at present



We can offer a full cut to size service on any quantity and in many cases are able to supply smaller panels when required.
